9 Inch TFT Touch Panel
The 9 Inch TFT Touch Panel is an industrial-grade 1024×600 TFT LCD module designed for embedded systems requiring stable performance, multi-touch accuracy, and long-term supply continuity. It supports RGB parallel interface and is widely used in HMI, medical, and industrial control applications.
Description
The 9 Inch TFT Touch Panel is an industrial-grade 1024×600 TFT LCD module designed for embedded systems requiring stable performance, multi-touch accuracy, and long-term supply continuity. It supports RGB parallel interface and is widely used in HMI, medical, and industrial control applications.
Technical Specifications
|
Parameter |
Details |
|
Display Size |
9 inches (diagonal) |
|
Resolution |
1024 × 600 pixels (16:9) |
|
Brightness |
450 nits (typ.), optional ambient light sensor |
|
Interface |
RGB (8/16/24-bit parallel bus) |
|
Viewing Angle |
IPS full view |
|
Pin Configuration |
50-pin FPC (gold-plated connectors) |
|
Driver IC |
HX8282 + HX8696 (TFT), GT911 (Touch) |
|
Touch Technology |
Projected capacitive (10-point multi-touch) |
|
Touch Accuracy |
±2mm |
|
Operating Temperature |
-20°C to 70°C |
|
Storage Temperature |
-30°C to 80°C |
|
Cover Lens |
Tempered glass, 6H hardness, anti-fingerprint coating |
|
Power Consumption |
3.2W typical, <0.5W standby |
|
Usage Environment |
IP54-rated usage; suitable for kitchen, industrial, medical environments |
Industrial Applications
HMI control panels
Medical monitoring interfaces
Smart kitchen equipment
Industrial automation systems
POS and retail terminals
Embedded control devices
Customization Options
Cover lens shape, thickness, and surface treatment
Brightness tuning with optional ambient light sensor integration
Cable length and FPC redesign for mechanical fit
Interface adaptation for system compatibility
Optical bonding (optional air or full bonding)
Firmware tuning for touch sensitivity (glove/wet operation support)
Manufacturing Quality & Reliability
100% functional and visual inspection before shipment
High/low temperature aging test (-30°C to 80°C stress validation)
Optical uniformity and brightness consistency testing
ESD protection and EMI stability verification
Full batch traceability system
RoHS-compliant production materials
Each 9 Inch TFT Touch Panel is validated for industrial operation stability before delivery.
OEM Project Workflow
Requirement definition (display + touch + interface)
Engineering drawing confirmation
Sample production and evaluation
Functional and environmental testing
Pilot run for validation
Mass production with stable supply control
FAQ
Q: What is the MOQ for this 9 Inch TFT Touch Panel?
A: Standard MOQ is 100–500 units depending on customization requirements.
Q: What is the lead time for samples and mass production?
A: Samples require 2–3 weeks, and mass production typically takes 4–6 weeks.
Q: What payment terms are supported?
A: T/T is standard, PayPal for samples, and LC available for long-term or large-volume orders.
Q: What trade terms do you support?
A: EXW, FOB, CIF, and DDP depending on customer logistics requirements.
Q: How is product quality ensured?
A: Each batch undergoes 100% inspection, aging tests, and full functional verification before shipment.
Q: What certifications are available?
A: RoHS is standard; CE/FCC certification can be provided upon request.
Q: What packaging method is used?
A: Anti-static trays, foam protection layers, vacuum moisture-proof bags, and export-grade cartons.
Q: Is long-term supply guaranteed?
A: Yes, BOM-controlled production ensures stable multi-year supply for OEM projects.
