8.9 Inch Multi Touch Capacitive Screen
The 8.9-inch Multi Touch Capacitive Screen utilizes PCAP projected capacitive touch technology, supports 10-point touch, and is suitable for industrial equipment, human-machine interfaces (HMIs), medical devices, self-service terminals, and intelligent control systems.
Description
What Is 8.9 Inch Multi Touch Capacitive Screen?
The 8.9-inch Multi Touch Capacitive Screen utilizes PCAP projected capacitive touch technology, supports 10-point touch, and is suitable for industrial equipment, human-machine interfaces (HMIs), medical devices, self-service terminals, and intelligent control systems.
Technical Specifications
|
Parameter |
Specification |
Note |
|
Diagonal Size |
8.9 Inches |
|
|
Active Area |
211.68mm x 79.38mm |
Custom areas available |
|
Technology |
Projected Capacitive (PCAP) |
|
|
Touch Points |
10 Points |
|
|
Surface Hardness |
6H (Pencil Hardness) |
Up to 8H optional |
|
Cover Lens Material |
Chemically Strengthened Glass |
Sapphire Glass optional |
|
Transmittance |
>88% |
With AG/AR treatment >85% |
|
Interface |
I²C, USB (HID compliant) |
Other controllers on request |
|
Operating Temperature |
-20°C ~ +70°C |
Extended range available |
|
Customization |
Yes |
Size, Shape, FPC, Logo Printing |
Why Choose Our 8.9 Inch Multi Touch Capacitive Screen?
Utilizing PCAP multi-touch technology, it supports precise 10-point touch input with rapid response speeds, thereby enhancing the device's interactive experience.
With a light transmittance exceeding 88%, it maintains high visibility-even after AG/AR surface treatments-effectively reducing glare and improving display quality.
It features a chemically strengthened glass cover with a surface hardness rating of 6H (with an optional 8H upgrade available), offering superior resistance to scratches and impact.
Mechanical Structure & Design Details
8.9-inch Ultra-Wide Design
Features an effective display area of 211.68 mm × 79.38 mm, making it ideal for bar-type displays and integration into specialized equipment.
Integrated Touch Structure
The touch layer and cover glass are highly integrated, ensuring structural stability and enhancing anti-interference capabilities.
Multiple Interface Options
Supports I²C and USB HID communication interfaces, facilitating rapid system integration.
Flexible Mounting Design
Supports embedded mounting, adhesive-based fixing, and custom mounting solutions.
OEM/ODM Customization Solutions
Custom Touchscreen Size and Shape
Custom Cover Glass
Custom Logo Silk-Screen Printing
Custom FPC Cable Direction and Length
Custom Interface and Control Solutions
AG/AR/AF Surface Treatments
Custom High-Hardness and Sapphire Glass
Packaging, Protection & Shipping
Protective Packaging Design
Features anti-static bags, EVA cushioning foam, and thickened cartons to minimize the risk of transit damage.
Reinforced Packaging for Bulk Orders
Supports palletization and shock-resistant packaging, suitable for export shipments.
Multiple Logistics Options
Supports shipping via DHL, FedEx, UPS, air freight, and sea freight.
FAQ
Q: How many touch points does this 8.9-inch capacitive touch screen support?
A: It supports 10-point multi-touch, offering sensitive touch response suitable for applications requiring complex interactive operations.
Q: Which interfaces are supported?
A: It supports standard I²C and USB HID interfaces; other control solutions can also be customized to meet specific project requirements.
Q: Do you support custom sizes and structures?
A: We support customization of size, shape, FPC cables, cover glass, and mounting structures.
Q: Is the screen surface scratch-resistant?
A: It features chemically strengthened glass with a standard hardness rating of 6H; an optional 8H high-hardness solution is also available for enhanced abrasion resistance.
Q: Can AG/AR anti-glare treatments be applied?
A: We support surface treatments such as AG (Anti-Glare), AR (Anti-Reflective), and AF (Anti-Fingerprint) to reduce glare and improve outdoor visibility.
Q: What types of devices is this suitable for?
A: It is widely used in industrial control equipment, medical devices, self-service terminals, smart home systems, and HMI (Human-Machine Interface) systems.
Q: What is the operating temperature range?
A: The standard operating temperature range is -20°C to +70°C; wider-temperature industrial-grade solutions are also available upon request.
Q: Do you support logo customization?
A: We support customization of logos via silk-screening, brand branding, and overall glass aesthetics.
Q: Are products tested before shipment?
A: All products undergo rigorous testing-including touch functionality, interface connectivity, stability, and visual inspection-before being shipped.
Q: What shipping methods are available?
A: We support shipping via DHL, FedEx, UPS, air freight, and sea freight; the most suitable shipping solution will be arranged based on the order volume.
